Simpson Strong-Tie® SDWS22600DB Timber Screw, 0.315 in Thread, 6-Lobe Drive, T40 Drive, Washer Head, 6 in OAL, Tan
  • Manufacturer: Simpson Strong-Tie
  • Brand Name: Simpson Strong-Tie®
  • Product Code: 528
  • Part Number: 1207012
  • MPN: SDWS22600DB
  • Min. Order Qty: 1
  • Qty. Interval: 1

The SDWS framing screw is designed and load-rated for replacing 16d, 10d and 8d nails in framing applications. The SDWS framing screw is superior to nails in holding power and pull-out resistance. It is code listed in IAPMO UES ER-192 and meets 2018 and 2021 IRC® and IBC® code requirements for most common wood framing applications.

Simpson Strong-Tie® Timber Screw, 0.315 in Thread, 6-Lobe Drive, T40 Drive, Washer Head, 3 in Thread Length, 6 in Overall Length, Tan, Additional Information: 0.22 in Dia Shank, SawTooth® Point

Additional Information      :      0.22 in Dia Shank, SawTooth® Point
Color      :      Tan
Drive Size      :      T40
Drive Type      :      6-Lobe
Head Type      :      Washer
Overall Length      :      6 in
Thread Length      :      3 in
Thread Size      :      0.315 in
