MiTek® THD412 1220162

MiTek® THD412

  1. pin-int
MiTek® THD412 Heavy-Duty Truss Hanger, 11 in H, 14 ga Gauge, Steel, G90 Galvanized
  • Manufacturer: MITEK INDUSTRIES
  • Brand Name: MiTek®
  • Product Code: THD412
  • Part Number: 1220162
  • MPN: THD412
  • Min. Order Qty: 1
  • Qty. Interval: 1

The THD412 Face Mount Hanger can be used to connect 4x12 or 4x14 plated wood trusses, rafters, or joists to masonry wall structures. Allowable loads are based on proper use of fasteners installed per manufacturer's specifications.

MiTek® Heavy-Duty Truss Hanger, 11 in Height, 3-5/8 in Width, 3 in Length, Material Gauge: 14 ga, Nail Fastener, 0.148 x 3 in Fastener, 1680 lb Load, Steel, G90 Galvanized, Additional Information: Face-Mount, 4 x 12 to 14 in Joist Size

Additional Information      :      Face-Mount, 4 x 12 to 14 in Joist Size
Fastener Size      :      0.148 x 3 in
Fastener Type      :      Nail
Finish      :      G90 Galvanized
Height      :      11 in
Length      :      3 in
Load Capacity      :      1680 lb
Material Gauge      :      14 ga
Material      :      Steel
Width      :      3-5/8 in
  • pdfSpecification Sheet https://assets.unilogcorp.com/571/ITEM/DOC/MiTek_THD412_Specification_Sheet.pdf
